Video format | PAL/NTSC |
Compression standar | H.264 |
Resolutio | 1080N/720P /960H/D1/CIF |
Playback quality | 1080N/720P /960H/D1/CIF |
Decoding capability | 1 channel 1080n real-time |
Video quality | level 1 to 6 can be configured |
Screen display | Support 1, 2, 3, 4 screen display |
Recording mode | Synchronous recording of sound and video |
Audio input | eight-way aviation connector interface |
Audio output | 1 VGA video output, 1 aviation connector audio and video output |
Alarm input | 4 digital inputs (four configurable positive/negative triggers) |
Disk interfac | 2.5 inch hard disk, maximum support 2T |
SD card | 1 SDXC high-speed card (maximum support 256G) |
GPS | support antenna insertion/unplugging/short circuit detection |
2G/3G/4G | support CDMA/EVDO/GPRS/WCDMA/FDD LTE/TDD LTE |
WIFI | 802.11b/g/n, frequency 2.4GHz |
Power input | DC: 8V~32V |
| Operating temperature | -20 -- +70℃ |
Siz | 162mm*180mm*50.5mm |
